A-ARC-10W33

10.1” WXGA LCD with P-cap Intel® Celeron® N3350 Rugged Touch Panel PC with IET Expansion

Anewtech Systems Industrial Panel PC Avalue Rugged Touch Computer A-ARC-10W33
  • 10.1” WXGA LCD with PCAP Multi-Touch
  • Onboard Intel® Celeron® N3350 SoC BGA Processor
  • 1 x 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600MTs SDRAM
  • Rich I/Os, 2 LAN, 2 COM, 4 USB, SIM Card Slot, Swappable Drive Bay, Speaker out for Flexible Expansion Modules
  • 1 x Mini PCIe Slot
  • Rugged Design for Vibration & Shock Protection, Cableless Design
  • Fanless Operation from -10 ~ 50°C
  • Wide Range DC Power Input from +9 ~ 36Vdc
Datasheet
Product Specification
Anewtech ARC-ARC-10W33  Industrial Touch Panel PC Avaule Rugged Panel PC
System Information
ProcessorOnboard Intel® Celeron® SoC BGA Processor
(Apollo Lake Platform N3350 CPU)
System MemoryOne 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1600Mhz SDRAM (Non-ECC)
Watchdog TimerH/W Reset, 1sec. ~ 65535sec./1sec.step
H/W Status MonitorMonitoring CPU & System Temperature and Voltage
CPU Cooler (Type)Fanless Heatsink
Expansion
Expansion1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe
1 x 80-pin IET interface
Storage
Storage1 x 2.5” Drive Bay(7mm HDD Restricted)
HDD/ SSD1 x SATA3
Other Storage Device1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe
Panel
LCD Size10.1" 16:10
Display TypeWXGA
B/L Inverter/ConverterLCD built in
Resolution1280x800
Pixel pitch0.1695mm(H) x 0.1695mm(V)
Luminance350 cd/m2
Contrast ratio800
Viewing angle85 (U), 85 (D), 85 (L), 85 (R)
Response time25 ms
BacklightLED
Touch TypePCAP Multi-Touch support up to 10 points
Touch Light Transmission88 %
Touch ControllerEETI
I/O
USB Port4 x USB3.0 (2 x Double deck)
COM Port1 x RS-232/422/485, selectable by BIOS, RS-485 supports Auto Flow, Pin-9 selected by Ring/+5V/+12V)
1 x RS-232
DIO16-bit GPIO
Expansion1 x mSATA supports on the 1st Mini PCIe slot, Auto switch for mSATA or Mini PCIe
1 x Optional by IET module
Other3 x Knockouts for Antenna Mounting
System Control
LED IndicatorHDD LED, Power LED
DC In/Out Characteristics
Power TypeAT/ATX
Audio
Audio CodecRealtek ALC888S
Speaker Output2 x 2W
Certifications
Certification InformationCE / FCC Class B
Ethernet
LAN Port2 x Intel I211AT for APL-M
Power Requirement
DC InputDC +9V ~ +36V, wide voltage single power input
TVS component for surge protection
Reverse current/voltage protection
DC Input ConnectorLockable DC Jack (Default)
optional for phoenix connector
ACPISingle power ATX Support S0, S3, S4, S5 and ACPI 3.0 Compliant
Power ModeAT/ATX
AdapterInput: 100 ~ 240Vac/ 50 ~ 60Hz Output: 60W Adapter (12V @ 5A Adapter) AC-DC Adapter
Mechanical & Environmental
Operating Temperature-10°C ~ 50°C
Storage Temperature-20°C ~ 60°C
Operating Humidity40°C @ 95% Relative Humidity, Non-condensing
Dimension (W x L x H)282.29 x 200.93 x 50.9mm
Weight2.17Kgs
Vibration TestWith SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis
Shock TestOperating with SSD/CFast/mSATA : MIL-STD-810G, Method 516.6, Procedure I, functional shock=20G
IP RatingFront Panel IP65
back cover IP41
Mounting KitWall / Stand / VESA 75mm x 75mm, 100mm x 100mm
Panel Mount with mounting kits
Power RequirementDC +9V ~ +36V, wide voltage single power input
TVS component for surge protection
Reverse current/voltage protection
Power ModeAT/ATX
System FanFanless
Construction - FrontDie Casting with Cover lens
Construction - RearBlack Die Casting
Relative Humidity40°C @ 95% Relative Humidity, Non-condensing
FanlessYes
DropISTA 2A, IEC-60068-2-32 Test:Ed
Software Support
OS InformationLinux, Windows 10
