A-HID-2340
23.8" Medical Panel PC Socketed Intel® 12th Gen Core™ i7/i5/i3 Processor
- Sleek light weight design
- 23.8” Full HD PCAP touch
- Socketed Intel® 12th Gen Core™ i7/i5/i3 Processor
- 1 COM, 2 LAN, 1 USB 2.0, 3 USB 3.0, 1 USB Type C
- 1 x M.2 Key B 3042/3052/2280, 1 x M.2 Key E for WIFI, 1 x M.2 Key M for storage
- 5-kv Isolation USB/ COM/ LAN ports by IET module
- Optional Webcam/ WIFI/ NFC/ Barcode Scanner
Datasheet
Product Specification
| System Information | |
| Processor | 12th Generation Intel® Core™ i7/i5/i3/Celeron Processor |
| Platform Controller Hub | Integrated in processor (SOC) |
| System Memory | One 262-pin DDR5 4800MHz SO-DIMM socket, supports up to 32GB Max (Min 8GB) |
| I/O Chipset | IT5782VG |
| Watchdog Timer | H/W Reset, 1sec. – 65535sec./min.1sec. or 1min. step |
| H/W Status Monitor | CPU temperature monitoring Voltage monitoring |
| TPM | Onboard NuvoTon NPCT754AADYX support TPM 2.0 (optional) |
| SBC | HID-2340 mother board |
| Expansion | |
| Expansion | 1 x M.2 Key B 3042/3052/2280 1 x M.2 Key E for WIFI 1 x IET expansion |
| Storage | |
| Storage | 1 x M.2 Key M storage (optional) 1 x 2.5" SSD (optional) |
| Audio | |
| Audio Codec | Realtek ALC888S |
| Speaker Output | 2 x 2W |
| Ethernet | |
| LAN Chipset | 1 x Intel® I225LM 1 x Intel® I226LM 1 x Isolation 5-kV Intel® I210AT (by IET Module) |
| Ethernet Interface | 10/100/1000/2500 Base-Tx GbE compatible |
| LAN Port | 2 x RJ-45 |
| Power Requirement | |
| DC Input Connector | Lockable DC Jack, +12V~+24V |
| Adapter | Medical grade Input: 100-240V~, 2.0-1.0A, 50-60Hz Output: 120W adapter (24V/5A adapter) |
| Power Mode | AT/ATX (ATX is default setting) |
| Software Support | |
| OS | Win10 / Linux |
| Certification | |
| Certification Information | CE : IEC/EN60601-1-2 FCC : Part 15 class B UL60601-1 |
| External I/O | |
| USB | 1 x USB 2.0 3 x USB 3.0 1 x USB type C (output for USB 3.1 & display, 5V/3A 15W, no power receiving function) 1 x Isolation 5-kV USB1.1 (by IET module) |
| Wireless LAN | Optional 802.11abgn+acR2+axR2 Wi-Fi 6E BT5.2 |
| Panel | |
| LCD Size | 23.8" |
| Display Type | Full HD |
| Resolution | 1920 x 1080 |
| Pixel pitch | 274.5 x 274.5 |
| Luminance | 250 cd/m2 |
| Contrast ratio | 3000 |
| Viewing angle | 89(U), 89(D), 89(L), 89(R) |
| Response time | 16ms |
| Backlight | LED |
| Touch Type | Projective capacitive multi-touch up to 10 points |
| Touch Light Transmission | 85% |
| Touch Controller | USB touch (EETI H8851A) |
| I/O | |
| COM Port | 1 x RS-232/422/485 1 x Isolation 5-kV RS-232/422/485 (by IET Module) |
| Reliability | |
| Operating Temp. | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temp. | -30°C ~ 70°C (-22°F ~ 158°F) |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Mechanical & Environmental | |
| Storage Temp. | -30°C ~ 70°C (-22°F ~ 158°F) |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| Weight | TBD |
| Vibration Test | With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis |
| Shock Test | With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms |
| IP Rating | Front IP65 Back IP54 |
| VESA | 75x75, 100x100 |
| System Fan | Fanless |
| Construction - Front | White plastic |
| Construction - Rear | White plastic |
| Finishing | Anti-microbial |
| Fanless | Yes |
| Color | White |
