ID-E3.S 5TS-P
Form Factor: E3.S; Flash Type: 3D eTLC; Interface: PCIe Gen 5 x4, Capacity: 1.92TB ~ 7.68TB
- Up to 14GB/s read and 10GB/s write performance
- High storage density up to 7.68TB in a single E3.S drive
- 1 DWPD endurance with 5-year warranty for long-term reliability
- PLP (iCell) technology for power loss protection
Model Name | E3.S 5TS-P |
| Flash Type | 3D eTLC |
| Interface | PCIe Gen 5 x4 |
| Form Factor | E3.S |
| Capacity | 1.92TB ~ 7.68TB |
| Sequential R / W (MB/sec, max.) | 14,000 / 10,000 |
| TBW (Max.) | 14,000 (Enterprise Workload) |
| Storage Temperature | -40°C ~ 85°C |
| Max. Power Consumption | 25W |
| Max. Channels | 16 |
| External DRAM Buffer | Ｙ |
| Features | PLP (iCell), AES, TCG Opal 2.0, S.M.A.R.T. |
| Series | Data Center SSD |
| Dimension (W x L x H/mm) | 76.0 x 112.75 x 7.5 |
| Vibration | 20G@[7 ~ 2000Hz] |
| Shock | 1500G@0.5ms |
| MTBF | 2 million hours |
PCIe Gen5 SSD redefines high-performance storage for next-generation data-intensive applications. Featuring a PCIe Gen 5 x4 interface and NVMe 2.0 protocol, this SSD delivers exceptional data transfer speed — up to 14GB/s read and 10GB/s write — making it ideal for demanding environments. Equipped with Error Correction Code (ECC) technology, it provides comprehensive End-to-End Data Path Protection (ETEP), ensuring secure data transmission between the host system and NAND Flash.
Engineered for enterprise reliability, the E3.S 5TS-P offers 1 DPWD endurance, advanced security features, and broad compatibility, ensuring robust data durability and seamless system integration.
Ordering Information
| Operating Temperature | Standard Grade (0°C ~ 70°C) |
| 1.92TB | DSE3S-1T9IX&#CAH@P |
| 3.84TB | DSE3S-3T8IX&#CAH@P |
| 7.68TB | DSE3S-7T6IX&#CAH@P |
Operating temperature based on temperature obtained from S.M.A.R.T.
& : 1 = Standard / 2 = TCG Opal
# : Flash mode (Internal use)
@ : F = Kioxia / H = Micron
E3.S 5TS-P specifications are subject to change.
