AD-ECU-1170
High-Performance All-in-One Gateway for Battery Energy Storage Systems
- Quad-core Cortex-A55 processor, 1.8GHz
- Connectivity: 4 GbE, 8 RS-232/485, 2 CAN, 1 mPCle and 1 M.2
- I/O: 20 DI, 6 DO, 8 Relay, 2 AI
- Battery-powered RTC, Watchdog, and optional TPM support
- Wide operating temperature range: -40~70°C
- Optional 5 sec power backup with Supercapacitor
- Supports IEC 61850, IEC 104, DNP3, Modbus, MQTT, and OPC UA
- Preloaded with Yocto Linux and EdgeLink or Ubuntu Linux
| Model | ECU-1170-551A |
| Power Supply | |
| Input Voltage | 10~30 VDC |
| Analog Input | |
| Channels | 2 |
| lnput Type | V, mA |
| Input Range | 0~10 V, 0~20 mA |
| General | |
| Humidity (Storage) | 5~95% RH (non-condensing) |
| Hardware | |
| LAN | 4 x 10/100/1000 Mbps |
| Watchdog Timer | 1~255 s |
| Certification | CE, FCC, UL |
| OS Support | Linux Yocto |
| Video Port | HDMI |
| I/O | 2 x CAN Bus |
| CPU | Rockchip ARM® RK3568J Quad-core Cortex-A55 |
| Memory | 1 x LPDDR4 with 4 GB |
| Expansion | 1 x Full-size mPCIe slot, 1 x M.2 B key 2280 |
| LED Indicators | PWR, Programmable LED |
| Storage | 1 x eMMC (32 GB), 1 x SD Slot |
| I/O Interface | |
| USB Ports | 1 x USB 2.0, 2 x USB 3.0 |
| Serial Ports | 8 x RS-232/485 |
| Environment | |
| Ingress Protection | IP30 |
| Operating Temperature | -40~70 °C (-40~158 °F) |
| Storage Temperature | -40~85 °C (-40~185 °F) |
| Vibration Protection | 1 Grms |
| Shock Protection | 15 G, half sine |
| Relay Output | |
| Channels | 8 Form A |
| Mechanical | |
| Mounting | Wall, DIN-rail |
| Form Factor | Passive Cooling and Front Accessible |
| Enclosure | SGCC |
| Dimension (W x H x D) | 183 x 108 x 43 mm |
| Expansion Function | |
| SIM card slot | Nano SIM card |
| Antenna | 4 x SMA hole |
| Wireless Communication | |
| Standard (Technology) | WIFI, LTE |
| Digital Input and Digital Output | |
| No. of Channels | 20-ch DI and 6-ch DO |
Within the broad Industrial IoT field, governments, equipment manufacturers, factory owners, and smart city investors are seeking solutions that can help them utilize powerful data analytics to raise service levels and reduce operational costs. This means that the demand for an easy and reliable way to extract data from field applications is increasing.
Industrial Communication Gateways are designed to simplify data acquisition and transmission. These solutions improve service quality by facilitating infrastructure connectivity, equipment monitoring, and energy consumption analysis. This allows manufacturers and organizations to obtain insights on usage behaviors and derive intelligence through the analysis of big data.
Intelligent Communication Gateways
Intelligent Communication Gateways are ARM-based robust platforms with wireless and Ethernet communication, and multiple protocol support.
Industrial-Grade Design and High Reliability
Open Platform and Flexible I/O Extension
Protocol Conversion and Edge to Cloud Solution
Azure and AWS Certified Device
