AS-iEPF-11000S
Expandable Edge AIoT Platform Support NVIDIA GPU (1~4pcs): RTX 6000 Ada, RTX 5000 Ada, RTX A4500 Ada, RTX 4000 Ada, RTX A4000 SFF Ada, RTX 2000 Ada
- Supported NVIDIA GPU (1~4pcs): RTX 6000 Ada, RTX 5000 Ada, RTX A4500 Ada, RTX 4000 Ada, RTX A4000 SFF Ada, RTX 2000 Ada
- Intel® Xeon® W-3500/3400 or W-2500/2400 Series Processor with W790 chipset
- 8 x 288-pin ECC RDIMM/RDIMM-3DS DDR5 4400/4800 MHz, up to 2TB
- 1 x PCIe x16 (Gen5), 3 x PCIe x16 (Gen4), 1 x PCIe x8 (Gen4), 1 x PCIe x4 (Gen4), 1 x USB 3.2 Gen2x2, 5 x USB 3.2 Gen2, 2 x
- USB 3.2 Gen1, 3 x USB 2.0, 1 x M.2 Key E, 2 x M.2 Key M, 1 x M.2 Key B, 6 x COM, 8 x SATA3
- 1 x Marvell 10 Gigabit LAN (optional), 2 x Intel 2.5 Gigabit LAN
- TPM 2.0 onboard IC
- Support Intel® vPro, VMD RAID 0/1/5/10
- ATX Power Supply 2000W at 200-240V
- Eight PCIe slots chassis to support up to 4pcs dual width graphic cards or 2pcs triple width graphic cards
Datasheet
Product Specification
| Processor System | |
| CPU | Intel® Xeon® W-3500/3400 or W-2500/2400 Series Processor |
| Chipset | Intel® W790 |
| Socket | LGA4677 |
| BIOS | AMI SPI 256 Mbit |
| Discrete Graphic Card Option | |
| iEPF-11000S Series NVIDIA Graphic Card Option | RTX 6000 Ada 48GB GDDR6, 300W, 1~4pcs RTX 5000 Ada 32GB GDDR6, 250W, 1~4pcs RTX 4500 Ada 24GB GDDR6, 210W, 1~4pcs RTX 4000 Ada 20GB GDDR6, 130W, 1~4pcs RTX 4000 SFF Ada 20GB GDDR6, 70W, 1~4pcs RTX 2000 Ada 16GB GDDR6, 70W, 1~4pcs |
| iEPF-11000S Series Intel Graphic Card Option | A770, 16GB GDDR6, 225W, 1~2pcs B580, 12GB GDDR6, 190W, 1~4pcs |
| MB Expansion Slot | |
| PCIe | Chassis supports Eight PCIe slots. MB supports Six PCIe x16 connectors. (PCIE1 connector supports Gen5 x16 signal and dual slot width, PCIE2 connector supports Gen4 x16 signal and single slot width, PCIE3 connector supports Gen4 x8 signal and single slot width, PCIE4 connector supports Gen4 x8 signal and single slot width, PCIE5 connector supports Gen4 x4 signal and single slot width, PCIE6 connector supports Gen4 x16 signal and dual slot width. PCIE4 signal can be PCIE Gen4 x16 if PCIE3 is not occupied) |
| M.2 | 1 x M.2 (Key E, 2230) with PCIe Gen3 x1, USB 2.0 and CNVi for Wireless 1 x M.2 (Key B, 3042/3052) with PCIe Gen3 x1, USB 3.2 Gen1, USB 2.0 and SIM for 4G/5G |
| SIM Socket | 1 x SIM socket connected to M.2 Key B |
| MB Rear I/O | |
| Ethernet | LAN1: Intel® I226LM with 10/100/1000/2500 Mbps, supports vPro LAN2: Intel® I226V with 10/100/1000/2500 Mbps LAN3: Marvell AQC113 with 10/100/1000/2500/5000/10000 Mbps (optional) |
| USB | 5 x USB 3.2 Gen2 1 x USB 3.2 Gen2x2 (Type-C, 5V/3A) |
| Audio | Realtek ALC897 HD, High Definition Audio. Line-In, Line-Out, Mic-In |
| COM | COM3, COM4 (RS-232) COM1, COM2 (RS-232/422/485) |
| MB Internal Connector | |
| USB | 2 x USB 2.0 (1 x 2.54 pitch header) 1 x USB 2.0 (vertical con) |
| COM | COM5, COM6 (RS-232) |
| GPIO | 4 x GPI, 4 x GPO |
| Memory | |
| Technology | Quad Channel ECC DDR5 4400/4800 MHz* *1DPC 4800 MHz Natively for Xeon® W9, Xeon® W7 and Xeon® W5 2DPC 4400 MHz Natively for Xeon® W9, Xeon® W7 and Xeon® W5 Supports 4400 MHz Natively for Xeon® W3, W5-3423 and W5-3433 |
| Capacity | 2TB |
| Socket | 8 x 288-pin RDIMM/RDIMM-3DS |
| Audio | |
| Interface | Realtek ALC897 HD, High Definition Audio. Line-In, Line-Out, Mic-In (Rear Side) |
| Ethernet | |
| Controller/ Speed | LAN1: Intel® I226LM with 10/100/1000/2500 Mbps, supports vPro LAN2: Intel® I226V with 10/100/1000/2500 Mbps LAN3: Marvell AQC113 with 10/100/1000/2500/5000/10000 Mbps (optional) |
| Security | |
| TPM | TPM 2.0 onboard IC |
| Storage | |
| M.2 | 1 x M.2(M2_M1) (Key M, 2242/2280/25110) with PCIe Gen4 x4 and SATA3 for SSD 1 x M.2(M2_M2) (Key M, 2260/2280/25110) with PCIe Gen4 x4 for SSD |
| SATA | Default support 1*3.5" internal SATA HDD bay, or up to optional 8-Bay 2.5" SATA hot-swap module in two 5.25" area 8 x SATA3, SATA3_0 shared with M.2 Key M1 |
| RAID | Intel® VMD RAID 0/1/5/10 **supported by identical interface (PCIE or SATA) PCIE interface: M.2 Key B + M.2 Key M x1 or x2 SATA interface: SATA port |
| Power Requirements | |
| MB Input Power | 1 x 24-pin ATX PWR connector 2 x 8-pin 12V PWR connector 1 x 8-pin and 1 x (6+2)-pin 12V PWR connector for PCIe AT/ATX Supported - AT : Directly PWR on as power input ready - ATX : Press button to PWR on after power input ready |
| Power Supply Unit | Rated Output Power 2000W at 200-240V/1500W at 115-200V/ 1200W at 100-115V, Input Voltage 100-240V, Input Current 15-12A, Input Frequency 60-50Hz |
