SH-SPCEL02/03
Mini Edge Computer with COM and DIO for Automation, SPCEL02 Intel Celeron® J6412, SPCEL03 Intel Atom® x6413E 3.00 GHz.
- Processor:
- SPCEL02 Intel Celeron® J6412 2.60 GHz
- SPCEL03 Intel Atom® x6413E 3.00 GHz
- 260 pin SO-DIMM, DDR4 3200MHz (Support up to 32 GB)
- Storage: SSD M.2 M 2280/ 2242
- Expansion Slot:
- 1x M.2 2242/2280 E Key slot support SATA Gen 1
- 1x SO-DOMM socket
Datasheet
Product Specification
| FORM FACTOR | Rugged aluminum chassis |
| PROCESSOR | SPCEL02 Intel Celeron® J6412 2.60 GHz SPCEL03 Intel Atom® x6413E 3.00 GHz |
| MEMORY | 260 pin SO-DIMM, DDR4 3200MHz Support up to 32 GB |
| VIDEO OUTPUT | HDMI 2.0b（4096x2160@60Hz）*1 |
| ETHERNET | Intel I226-v (PCIe) LAN controller Support Wake-On-LAN function |
| STORAGE INTERFACE | SSD M.2 M 2280/ 2242 With M.2 E-Key WLAN sku, only 2242 can support |
| FRONT PANEL | 2x USB 3.2 Gen2（Type A）*2 USB 2.0 Type A*1 RJ-45（Intel 2.5G Lan）*2 |
| BACK PANEL | DIO*1 RS-232/422/485（DB-9*1 |
| DIMENSIONS | 120（L） x 75（W） x 51（H） mm |
| POWER | 12V~24V DC in by 3-pin terminal block |
| ACCESSORIES | VESA Mount 100 x 100 mm Ear Mount Din Rail Mount Din Rail Clip |
| EXPANSION SLOT | 1x M.2 2242/2280 E Key slot support SATA Gen 1 1x SO-DOMM socket |
| OS SUPPORT | Windows 10/11 IoT Enterprise 64bit O.S Linux |
| NET WEIGHT | 0.7KG |
| CERTIFICATION | Safety: CB, cTUVus, BSMI, UKCA EMC: FCC Class A, CE Mark, VCCI, BSMI, RCM, UKCA, EAC RoHS Compliance Compliant with EN 50155 OT1 and EN 50121-3-2 standards Compliant with MIL-STD-810G |
| OPERATING TEMPERATURE | 0℃~40℃（SPCEL02） -20℃~60℃（SPCEL03） |
