SH-XH610 / XH610V
Embedded System supports Intel® 12th Generation Core™ processor. Triple Displays support
- Intel® 12th Generation Core™ processor
- Intel® Optane™ Memory Ready
- M.2 2280/2260/2242 Type M slot and an M.2 2230 Type E slot
- two 2.5” HDD/ SSD and a slim ODD or three 2.5” HDD/SSD
- Triple Display: 1 x HDMI 2.0b, 1 x DisplayPort, 1 x VGA
- Up to 5 additional COM Ports
- Rich Connectivity and High-speed Intel® 2.5GbE LAN
Product Specification
| PROCESSOR | Support Intel® 12th Generation Core™ i3/i5/i7/i9, Pentium®, Celeron® LGA1700 CPU max. TDP 65W |
| CHIPSET | Intel H610 Express chipset |
| MEMORY | 2 x DDR4 SODIMM slots,32GB per DIMM (Max 64GB) DDR4 3200 MHz |
| VIDEO OUTPUT | HDMI + Display + D-Sub (VGA) port triple display |
| AUDIO | Realtek ALC662/ALC897/ALC888S 5.1 channel High Definition Audio |
| ETHERNET | (1)Intel GbE Lan / (1)Intel 2.5 GbE Lan 10Mb/s,100Mb/s,1Gb/s operation Support Wake-On-LAN function Support Teaming function |
| STORAGE INTERFACE | SATA 6.0Gb/s interface |
| ONBOARD CONNECTORS | (3) SATA connectors (1) 1x4 pin USB 2.0 header (2) 4pin fan connectors (1) SATA power connector(5V) (1) SATA power connector(12V) (1) Auto power on header (1) RS232 voltage switch (4) RS232 connectors (1) Battery connector |
| FRONT PANEL | (2) USB 2.0 ports (2) USB 3.2 Gen1 ports (Include Type C x 1) (1) Microphone-In (1) Earphone-Out (1) Power-On button (1) Power LED (1) HDD LED |
| BACK PANEL | (2) RJ45 Gigabit LAN port w/LED (1) Display port (1) HDMI (1) D-Sub (VGA) port (2) USB 2.0 ports (2) USB 3.2 Gen1 ports (1) RS232 (1) RS232/RS422/RS485 (1) Line in port (1) Line out port (1) MIC in port (1) Clear CMOS button (1) DC in (1) Kensington lock (2) Wireless Antenna fixture |
| DRIVE BAYS | (1) 2.5" HDD / SSD bay (1) Slim ODD bay. User can install either 1 Slim ODD or (1) 2.5" HDD/SSD |
| DIMENSIONS | XH610V: 240(L) x 200(W) x 72(H) mm XH610 : 238(L) x 200(W) x 72(H) mm |
| POWER | 120W Power Adapter Input:100- 240V AC 19V 6.32A |
| ACCESSORIES | XPC Multilanguage Quick User Guide XPC DVD Driver 1* Power cord 1* SATA cable (pre-install for HDD) 1* SATA cable (pre-install for ODD) 1* 4 pin to SATA power cable Screws |
| EXPANSION SLOT | (1) M.2 2280 Type M key socket (1) M.2 2230 Type E Key socket |
| OS SUPPORT | Windows 11 64 bit O.S Linux |
| REMARK | 1. PHD4 3.5" HDD rack accessory can support XH310/XH310V/XH310R/XH310RV/XH610/XH610V |
SH-XH610 and XH610V feature robust performance and can be customized to drive highly interactive kiosks, vending machines, digital signage, and surveillance applications. Equipped with Intel® H610 chipset, it supports Intel® 12th LGA1700 65W processors and delivers 4K UHD video content.
In terms of extra I/O capabilities, the series features HDMI 2.0b, DisplayPort, VGA, USB 3.2 Gen 1, USB 2.0, RS232, M.2, and 2.5 Gigabit LAN. Furthermore, its slim metal chassis is VESA mount compliant, allowing 24/7 operation even in 50⁰C environments.
