AD-UNO-1372G

Intel® Atom™ Quad-Core Small Size Control DIN-rail PC w/ 3 x GbE, built-in 4GB DDR3L, 2 x mPCIe

Anewtech-Systems Embedded-PC AI-Inference-System AD-UNO-1372G Advantech DIN Rail Controller Automation PC
  • Intel® Atom E3845 1.91GHz processor with 4GB DDR3L Memory
  • 3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI, Audio, iDoor, mSATA, 2 x mPCIe, 1 x SATA, 4 x DI, 4 x DO, 1 x Power Terminal
  • Compact with Fanless Design
  • Dual Power Input for avoiding Power Down Time
  • Exchangeable RTC Battery with easy Access on the Top
  • Digital I/O with Isolation Protection for Sensing and controlling
  • Diverse system IO and Supports Fieldbus Protocol by iDoor Technology as a Protocol Gateway
  • 3G/GPS/GPRS/Wi-Fi Communication by iDoor Technology as a Communication Gateway
  • Supports MRAM by iDoor Technology
  • LAN Redundancy (Teaming)
Datasheet
AD-UNO-1372G.pdf
Product Specification
ModelUNO-1372G-E3AE
Environment
Ingress ProtectionIP40
Operating Temperature-20~60 °C (-4~140 °F)
Relative Humidity95% RH (non-condensing)
Shock Protection50 G, half sine
Storage Temperature-40~85 °C (-40~185 °F)
Vibration Protection5 Grms, random
Hardware
CertificationCB, UL, CE, FCC, CCC, BSMI
CPUIntel® Atom® E3845 1.91GHz Quad-Core
Graphics EngineIntel® HD Graphics
Memory1 x SO-DIMM with 4 GB DDR3L 1333 MHz
OS SupportMicrosoft® Windows 10 2019 LTSC, WES7, Linux
Power Input9~36 VDC
Storage1 x mSATA (shared with mPCIe), 1 x 2.5" SSD/HDD bay
I/O Interface
AudioLine-Out
Displays1 x VGA, 1 x HDMI
Expansion2 x Full-size mPCIe Slot
LAN Ports3 x 10/100/1000 Mbps
Power Connector1 x 4-Pin Terminal Block
Serial Ports1 x RS-232, 1 x RS-422/485
USB Ports1 x USB 3.0, 2 x USB 2.0
Local I/O
General Digital I/O4-ch DI, 4-ch DO
Mechanical
Dimension (W x H x D)85 x 139 x 152 mm
EnclosureAluminum housing
Weight (Net)1.6 Kg (3.5 lb)
