SH-P15AL01
15.6-inch Multi-Touch Panel PC. 12th Gen Intel® Alder Lake Core™ Processor
- Processor
- 12th Gen. Intel® Alder Lake-U/UE
- Intel® Core™ i7-1265UE (Supports vPro)
- Intel® Core™ i7-1255U(Supports vPro)
- Intel® Core™ i5-1245UE (Supports vPro)
- Intel® Core™ i5-1235U (Supports vPro)
- Intel® Core™ i3-1215UE
- Intel® Core™ i3-1215U
- Intel® Core™ Celeron 7305
- Memory: 2 x 262 pin SO-DIMM Dual Channel DDR5 4800MHz (Max. 64GB)
Datasheet
Product Specification
| System | |
| Processor | 12th Gen. Intel® Alder Lake-U/UE Intel® Core™ i7-1265UE (Supports vPro) Intel® Core™ i7-1255U(Supports vPro) Intel® Core™ i5-1245UE (Supports vPro) Intel® Core™ i5-1235U (Supports vPro) Intel® Core™ i3-1215UE Intel® Core™ i3-1215U Intel® Core™ Celeron 7305E |
| Memory | 2 x 262 pin SO-DIMM Dual Channel DDR5 4800MHz (Max. 64GB) |
| Display and Touch Screen | |
| Display | 15.6” 1920x1080 Full HD LED with 10-Point Capacitive Multi-Touch |
| Brightness | 250/350 nits (default 350nits) |
| Contrast | 1000:1 |
| Graphics | |
| Chipset | Intel® UHD Graphics |
| Display Interface | Supports two independent displays 1 x HDMI 2.0: (4K / 60fps) 1 x DVI-I: 1920 x 1080@60Hz (optional daughter board) 1 x VGA (optional daughter board) |
| Storage | |
| Storage | 1 x M.2 2280, M key (PCIe x4 or SATA, either one) Option: 1 x M.2 2280, M key, SSD SATA I/F, Slidable design 1 x M.2 2280, M key, SSD SATA I/F, Fixed design (Either one of above) |
| Audio | |
| Audio Codec | Realtek ALC8885-VD |
| Network | |
| Ethernet | 1 x RJ-45 Lan Intel® 2.5 GbE 1 x RJ-45 2nd Lan (optional) (Support Wake on Lan) |
| WLAN | 1 x M.2 2230, M key with Realtek RTL8821CE 802.11a/b/g/n/ac + Bluetooth 5.0 with 2 internal antenna (default) / external antenna (optional) |
| I/O Interface | |
| LAN | 1 x RJ-45 Lan 2.5 GbE 1 x RJ-45 2nd Lan (optional) (Support Wake on Lan) |
| Serial Ports | 1 x RS-232(DB-9) 2 x RS-232/422/485 (DB-9) (RS-232 with power supply: ring in/ 5V (standard) & 12V (with specific optional board) |
| USB | 4 x USB3.2 Gen2 (Type A) |
| Audio | 1 x Line-out 1 x Mic-in |
| Power | |
| Adapter | 19V/4.7A 90W extenal adapter |
| Power | 9-36V DC-in (Optional wide range board) |
| Watchdog Timer | |
| Watchdog Timer | 255 Sec. |
| OS Support | |
| OS Support | Windows 10/11 IOT 64bit Linux 64bit |
| Mechanism | |
| IP Rating | IP65 Front Panel Protection |
| Mounting | VESA Mount (100 x 100mm) |
| Dimension (WxHxD) | 394 mmx 256mm x 48.9 mm |
| Weight | 4.6kg |
| Environment | |
| Operating Temperature | 0 ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Relative Humidity | 10% - 90% RH (non-condensing) |
| EMC | CE, FCC, VCCI BSMI |
| Safety | CB, cTUVus, CEC, BSMI |
| RF | EU, US, Taiwan |
