A-OFP-21W38
21.5” Open Frame Panel PC. Intel® Core™ SoC i7/i5/i3 Processor
- 21.5” Full-HD Open frame panel PC with PCAP Touch
- Onboard Intel® Core Soc i7/i5/i3 & Celeron® BGA Processor
- 2 x 260-pin DDR4 3200 MHz SO-DIMM supports up to 64GB
- 1 x M.2 Type B 3042/3052/2242/2260/2280 (with 1 x PCI-e x1 (default) or SATA,
- USB 3.0 with 1 x SIM card slot, support WWAN+GNSS or NVMe SSD
- 2x GbE LAN, 4 x USB 3.0, Line-out, Mic-in, 1 x COM, DP++, HDMI/DP
Datasheet
Product Specification
| System Information | |
| Processor | Onboard Tiger Lake U 11th Intel® Core™ SoC i7/i5/i3 & Celeron® BGA Processor |
| System Memory | Default with 4GB DDR4 Memory Option supports up to 64GB DDR4 3200MHz SO-DIMM |
| I/O Chipset | EC iTE IT8528 |
| BIOS Information | AMI uEFI BIOS, 256Mbit SPI Flash ROM |
| Watchdog Timer | H/W Reset: 1sec. ~ 65535sec./min. and 1sec. or 1min./step |
| H/W Status Monitor | Monitoring System Temperature and Voltage with Auto Throttling Control |
| CPU Cooler (Type) | Fanless Heatsink |
| Board | EMX-TGLP |
| Expansion | |
| Expansion | 1 x M.2 (2230) E-Key support WiFi module |
| Storage | |
| Storage | Default with 128GB M.2 SATA Other Storage Device Reserve space for 1 x 2.5” SSD (by option) |
| Other Storage Device | Reserve space for 1 x 2.5” SSD (by option) |
| Panel | |
| LCD Size | 21.5", 16:9 |
| Display Type | Full HD |
| B/L Inverter/Converter | LCD built in |
| Resolution | 1920 x 1080 |
| Pixel pitch | 247.95um(H) x 247.95um(V) |
| Luminance | 500 cd/m² |
| Contrast ratio | 1000 |
| Viewing angle | 89 (U), 89 (D), 89 (L), 89 (R) |
| Response time | 14 ms |
| Backlight | LED |
| Touch Type | Projective Capacitive Multi-Touch supports up to 10 points |
| Touch Light Transmission | 89 % |
| Touch Controller | EETI |
| I/O | |
| USB Port | 4 x USB 3.0 2 x USB 2.0 (option) |
| COM Port | 1 x RS232(default)/RS422/485, 4 x RS232(option, pin9 without power) |
| GPIO | 16bit GPIO |
| Expansion | 1 x M.2 (2230) E-Key support WiFi module |
| Other | 6 x Antenna Mounting with Dust Cover (Reserve) |
| DC In/Out Characteristics | |
| Power Type | AT/ATX |
| Display | |
| Graphic Chipset | Intel® HD Graphics 500 |
| Spec. & Resolution | 2 x DP++: 1920 x 1080@60 Hz |
| Audio | |
| Audio Codec | Realtek ALC897 |
| Audio Interface | Mic-in, Line-out |
| Audio Amplifier | 2 x Stereo Class-D 3W Audio Amplifier |
| Certifications | |
| Certification Information | CE / FCC Class A |
| Ethernet | |
| LAN Chipset | 1 x Intel® I219LM Gigabit Ethernet PHY (LAN1) 1 x Intel® I225LM 2.5 Gigabit Ethernet (LAN2) |
| Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
| LAN Port | 2 x RJ45 |
| Mechanical & Environmental | |
| Operating Temperature | 0°C ~ 45°C |
| Storage Temperature | -20°C ~ 60°C |
| Operating Humidity | 0% ~ 90% Relative Humidity, Non-condensing |
| Dimension (W x L x H) | 502 x 294 x 54 mm |
| Weight | 5.0 Kgs |
| Vibration Test | With M.2 SATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 0.5hr/axis |
| Shock Test | Operating with M.2 SATA : IEC 60068-2-27 testing procedures, 10G for operation mode |
| Mounting Kit | Panel / Wall Mount with mounting kits, VESA 100mm x 100mm |
| Power Requirement | +12V~24V DC in 3 pins Phoenix connector and Power Din DC Jack Extend Power Connector for Reset |
| Power Mode | AT/ATX |
| System Fan | Fanless |
| Relative Humidity | 0~90% Relative Humidity, Non-condensing |
| Fanless | Yes |
| Drop | ISTA 2A, IEC-60068-2-32 Test:Ed |
| Software Support | |
| OS Information | Windows 10 IoT, Linux, Windows 11 (by option) |
