SYS-E403-13E-FRN2T
Intel 5th / 4th Gen Intel Xeon embedded system. Support 3 PCIe 5.0 x16 (FHFL) slots, 2 10GbE LAN
- Support 5th and 4th Gen Intel® Xeon® Scalable processors
- Up to 8 DIMMs and total 2TB 3DS ECC DDR5-5600 RDIMM
- 3x PCIe5.0 x16 slot
- 2x 10 Gigabit Ethernet Ports
- Up to 4x 2.5" U.2 NVMe drive(2 Hot-swap, Optional 2 fixed)
Datasheet
Product Specification
| Product SKUs | SuperServer SYS-E403-13E-FRN2T |
| Motherboard | Super X13SEW-TF |
| Processor | |
| CPU | Single Socket E (LGA-4677) 5th Gen Intel® Xeon® / 4th Gen Intel® Xeon® Scalable processors |
| Core Count | Up to 32C/64T; Up to 60MB Cache |
| Note | Supports 85W - 350W TDP CPUs (Air Cooled)* *Air Cooled CPUs with TDP over 300W only supported under specific conditions. |
| System Memory | |
| Memory | Slot Count: 8 DIMM slots Max Memory (1DPC): Up to 2TB 5600MT/s ECC DDR5 RDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices | |
| NVMe | NVMe; RAID 0/1 support(Intel® VROC RAID key required) |
| Chipset | Intel® C741 |
| Network Connectivity | 2 RJ45 10GBASE-T with Intel® X550-AT2 1 RJ45 1GbE with Realtek RTL8211F PHY (dedicated IPMI) |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input / Output | |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) 2 RJ45 10 GbE LAN port(s) (Intel® X550-AT2) |
| USB | 2 USB 2.0 Type-A port(s) (rear) 4 USB 3.2 Gen1 Type-A port(s) (Rear) |
| Video | 1 VGA port(s) (Rear) |
| Management | |
| Power configurations | Power-on mode for AC power recovery ACPI Power Management |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| Chassis | |
| Form Factor | Fan-based Embedded |
| Model | CSE-E403BiF-000NDBP2 |
| Dimensions and Weight | |
| Height | 4.62" (117.348 mm) |
| Width | 10.5" (266.7 mm) |
| Depth | 16" (406.4 mm) |
| Package | 10.4" (H) x 16.4" (W) x 26" (D) |
| Weight | Gross Weight: 24.5 lbs (10.95 kg) Net Weight: 18.5 lbs (8.16 kg) |
| Available Color | Black |
| Front Panel | |
| LED | HDD activity LAN1 activity LAN2 activity Power status reset status System information |
| Buttons | Power On/Off |
| Drive Bays / Storage | |
| Drive Bays Configuration | Default: Total 2 bay(s) 2 front hot-swap 2.5" NVMe drive bay(s) Option A: Total 2 bay(s) 2 internal fixed 2.5" SATA* drive bay(s) (*SATA support may require additional storage controller and/or cables, please see the optional parts list for details) |
| M.2 | 1 M.2 PCIe 3.0 x2 NVMe slot(s) (M-key 2280/22110) |
| System Cooling | |
| Fans | 3x 8cm heavy duty fans with optimal fan speed control 80x80x38mm Fan(s) |
| Power Supply | 800W Redundant Platinum Level power supplies |
| Dimension (WxHxL) | 54.5 x 40.25 x 220 mm |
| +12V | Max: 62.5A / Min: 0.5A (100Vac-127Vac) Max: 66.6A / Min: 0.5A (200Vac-240Vac) Max: 66.6A / Min: 0.5A (230Vdc-240Vdc) |
| 5V SB | Max: 4A / Min: 0A |
| AC Input | 750W: 100-127Vac / 50-60Hz 800W: 200-240Vac / 50-60Hz 800W: 230-240Vdc / 50-60Hz |
| Output Type | Backplanes (gold finger) |
| Operating Environment | |
| Environmental Spec. | Operating Temperature: 0°C ~ 45°C (32°F ~ 113°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
