SYS-111AD-WRN2
1U UP short-depth edge server with 2 internal 2.5" drive bays and PCIe 5.0
- Intel® 14th/13th/12th Gen Core i9/i7/i5/i3 (ADL/RPL-S) Processor in LGA1700 Socket with R680E Chipset
- 4 DIMM slots, DDR5-4400MHz memory, support up to 128GB
- 1x dedicated IPMI LAN, 2x 2.5GbE BaseT LAN ports via Intel® I226 Controller
- 800W 100-240Vac Platinum Single Power Supply (can be upgraded to redundant power supply)
Key Applications
- Virtualization
- Firewall Applications
- Edge/Cloud Computing Services
- CDN/vCDN/Cloud CDN
- vRAN/o-RAN
Datasheet
Product Specification
| Product SKUs | SuperServer SYS-111AD-WRN2 |
| Motherboard | Super X13SAW-F |
| Processor | |
| CPU | Single LGA-1700 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 Processors |
| Note | Supports up to 80W TDP CPUs (Air Cooled) |
| System Memory | |
| Memory | Slot Count: 4 DIMM slots Max Memory (2DPC): Up to 128GB 4400MT/s ECC/non-ECC DDR5 UDIMM |
| Memory Voltage | 1.1V |
| On-Board Devices | |
| Chipset | Intel® R680E |
| Network Connectivity | 2 RJ45 2.5GbE with Intel® I226 |
| Input / Output | |
| LAN | 1 RJ45 1 GbE Dedicated IPMI LAN port(s) 2 RJ45 2.5 GbE LAN port(s) (Intel® I226) |
| USB | 2 port(s) |
| Video | 1 VGA port(s) 2 DisplayPort 1.4a port(s) |
| System BIOS | |
| BIOS Type | AMI 32MB SPI Flash |
| BIOS Features | ACPI 6.5 SMBIOS 3.6 or later UEFI 2.8 Plug and Play (PnP) USB Keyboard support |
| Management | |
| Software | SuperCloud Composer Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) New! |
| Power configurations | 800W 100-240Vac Platinum Single Power Supply (can be upgraded to redundant power supply) |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
| Temperature | SuperDoctor® 5 System resource alert via SuperDoctor®5 Platform Environment Control Interface (PECI) 3.0 support |
| Chassis | |
| Form Factor | 1U |
| Model | CSE-514-R00RWNP |
| Dimensions and Weight | |
| Height | 1.7" (43 mm) |
| Width | 17.2" (437 mm) |
| Depth | 16.9" (429 mm) |
| Package | 8" (H) x 27" (W) x 24" (D) |
| Weight | Gross Weight: 25.2 lbs (11.43 kg) |
| Available Color | No Paint |
| Front Panel | |
| LED | Fan Fail/System Over Heat LED HDD activity LED Network Activity LEDs Power status LED |
| Buttons | Power On/Off button System Reset button |
| Expansion Slots | |
| PCI-Express (PCIe) Configuration | Default 2 PCIe 5.0 x8 FHFL slot(s) 1 PCIe 4.0 x4 LP slot(s) Option A 1 PCIe 5.0 x16 (in x16) FHFL double-width slot(s) 1 PCIe 4.0 x4 (in x8) HHHL slot(s) |
| Drive Bays / Storage | |
| Drive Bays Configuration | Default: Total 2 bay(s) 2 internal fixed 2.5" NVMe/SAS/SATA drive bay(s) |
| M.2 | 2 M.2 NVMe slot(s) (M-key 2280/22110) 1 M.2 PCIe 3.0 x4 NVMe slot(s) (M-key 2280) 1 M.2 PCIe 4.0 x4 NVMe slot(s) (M-key 2280/22110) |
| System Cooling | |
| Fans | 5 Heavy duty counter-rotating 4cm Fan(s) |
| Power Supply | 1x 800W Redundant power supply |
| Operating Environment | |
| Environmental Spec. | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
