AD-ADAM-4520I

Isolated Wide Operation Temperature RS-232 to RS-422/485 Converter

Anewtech Systems Advantech RS-232/422/485 Converter AD-ADAM-4520I
  • Wide Operating Temperature: -40 ~ 85° C
  • Power inout: 10 to 48 VDC
  • Automatic RS-485 data flow control
  • 3000 VDC isolation protection
  • Surge protection RS-485 data line
Datasheet
Product Specification
Anewtech Advantech ADAM I/O Module RS-232/422/485 Serial Converter AD-ADAM-4520
ModelADAM-4520I-AE
Environment
Isolation Voltage3,000 VDC
Operating Temperature-40~85 °C (-40~185 °F)
General
Connectors1 x DB9 female connector, 1 x 10-pin plug-in screw terminal
Power Requirements
Input Voltage10~48 VDC
Serial Communication
Baud Rate (bps)1200 bps~115.2 kbps
Communications
Converter/RepeaterRS-232 to RS-422/485

AD-DAM-4520I (RS-232 to RS-422/485 converter) is designed more rugged than previous models which have wider operating and storage temperatures, can accept a wider power input, and have excellent anti-noise design. Moreover,it provide ssignal isolation (3,000VDC) protection and power surge (50V) protection. These industrial-grade features ensure robust and reliable operation in harsh environment applications.
