WM-S101G7
10.1" ARM Genio 700 2 x A78 + 6 x A55 Android Rugged Tablet
- 10.1” 1920x1200 LED Panel with PCAP Touch
- Android 13.0
- 4G RAM + 64G eMMC
- ARM Genio 700 2 x A78 2.2GHz + 6 x A55 2.0GHz
- Optional WWAN 4G and 5G
- MIL-STD-810H Shock / Drop / Vibration Compliant
- Optional Barcode Reader and NFC Reader
Datasheet
Product Specification
| Display | |
| Size | 10.1 inches |
| Resolution | 1920x1200 |
| Type | Projected Capacitive Multi Touch |
| Panel Brightness | 800.0 nits |
| Contrast Ratio | 800:1 |
| View Angles | 85,85,85,85 |
| Bonding | Optical Bonding for Sunlight Viewability |
| Viewability | Anti-Glare touch treatment |
| Touch Mode | Support Hand / Gloves and Rain Mode |
| System Specification | |
| Processor | Qualcomm® 6490 (Octa-Core 2.7GHz) |
| Memory | 6GB |
| Storage | 128GB |
| Operating System | Android 13.0 |
| WLAN | Support |
| BT | Support |
| WWAN | 4G (Optional) 5G (Optional) |
| GNSS | GPS/GLONASS |
| RFID | NFC (Read / Write, Peer to Peer mode) (Optional) |
| Sensors | Ambient Light Sensor, E-Compass, Gyro, Acceleration Sensors |
| Camera | |
| Front Camera | 8MP Camera |
| Rear Camera | 16MP Camera with LED Auxiliary Light (Auto Focus) |
| Mechanical | |
| Dimension | 271.9 x 197.3 x 19.5 mm |
| Weight | 1.2 kg (2.65 lbs) with standard battery, 1.4 kg (3.1 lbs) with optional high capacity battery |
| Cooling System | Fanless Design |
| IO Ports | |
| USB Port | 1 x USB 3.0 Type C OTG (Type C support Power Delivery) 1 x USB 2.0 Type A |
| Audio | 1 x Audio Combo connector (Mic in or Line Out) 1 x Built-in Mic 2 x Speaker |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x SIM Card Slot |
| Indicator | 1 x LED Indicators (Power, Battery) |
| Docking Connector | 1 x Docking Connector |
| Environment | |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -30°C to 70°C |
| Shock | MIL-STD-810H Method 516.8 Procedure I |
| Vibration | MIL-STD-810H Method 514.8 Procedure I |
| Drop | MIL-STD-810H Method 516.8, 4 ft |
| IP rating | IP65 |
| Certification | |
| Certification | CE, FCC |
| Control | |
| Button | 1 x Volume +/-, 1 x Home Button, 1 x ,Return Button, 1 x Power Button, 1 x Function Button |
| Power | |
| Battery | 7.7V, typ. 5900 mAh LiPolymer Battery (2S1P) 7.4V, typ. 10280 mAh LiPolymer Battery (2S2P) (Optional) Warm swappable function (Optional) |
| Battery Operating Time | 8Hr |
| Power Rating | 19V |
| Adapter | 19V 3.42A Adapter |
| Security Function | |
| SOTI MobiControl | SOTI MobiControl Compliance |
| Kensington Lock | Kensington Lock |
| Accessory | |
| Accessory | Adapter and Power Cord Standard Battery Capacitive Stylus |
| Optional Accessory | Desk Dock Vehicle Dock Vehicle Cradle Metal Vehicle Dock Battery Charger Hand Strap VESA Mount Kit Shoulder Strap Carry Bag Vehicle Charger Micro SD Card HDMI Adapter |
| Barcode Scanner | |
| Barcode Scanner | 1D/2D Barcode Reader (Optional) |
