AS-2015HS-TNR

2U Hyper AMD Server. 12 hot-swap 3.5" drive bays and up to 8 PCIe 5.0 slots

Single AMD EPYC™ 9004/9005* Series Processor
(*AMD EPYC™ 9005 series drop-in support requires board revision 2.x)
Support up to DDR5 24 DIMM slots (2DPC)
Optional PCIe slot configurations up to 8 PCIe 5.0 x8 or 4 PCIe 5.0 x16 slots or mix and match
Flexible networking options with 1 AIOM networking slot (OCP NIC 3.0 compatible)
12 Hot-swap 3.5"/2.5" NVMe/SATA/SAS drive bays
2 M.2 PCIe 3.0 NVMe slots
Support up to 4 GPUs

Key Applications

Virtualization
Software-defined Storage
AI Inference and Machine Learning

Cloud Computing
Enterprise Server

Datasheet

AS-2015HS-TNR.pdf

Product Specification

Anewtech-Systems-Rackmount-Server-Supermicro-AS-2015HS-TNR-superserver Supermicro Singapore Supermicro Servers

Anewtech-Systems-Rackmount-Server-Supermicro-Hyper-Superserver-AS-2015HS-TNR.

Product SKUs	A+ Server AS -2015HS-TNR (Black front & sliver body)
Motherboard	Super H13SSH
Processor
CPU	Single processor(s) AMD EPYC™ 9004/9005 Series Processors (* AMD EPYC™ 9005 Series drop-in support requires board revision 2.x)
Core Count	Up to 160C/320T
Note	Supports up to 400W TDP CPUs * Air Cooled CPUs with TDP over 290W only supported under specific conditions. This system supports AMD EPYC™ 9004/9005 Series processors up to 400W TDP
GPU
Max GPU Count	Up to 4 double-width GPU(s)
Supported GPU	NVIDIA PCIe: RTX A6000, RTX 6000 Ada Generation, L40S
CPU-GPU Interconnect	PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect	PCIe
System Memory
Memory	Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 3TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) Max Memory (2DPC): Up to 6TB 4000MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) Max Memory (1DPC): Up to 4.5TB 5200MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor) Max Memory (2DPC): Up to 9TB 4400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor)
Memory Voltage	1.1 V
On-Board Devices
Chipset	System on Chip
Network Connectivity	Via AIOM
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
LAN	1 Dedicated IPMI LAN port
USB	2 USB 3.0 port(s) (2 rear)
Video	1 VGA port(s)
System BIOS
BIOS Type	AMI 256MB SPI Flash
BIOS Features	ACPI 6.4 Plug and Play (PnP)SM BIOS 3.5 or later UEFI 2.8USB Keyboard support
Management
Software	IPMI 2.0 KVM with dedicated LAN Super Diagnostics Offline SuperDoctor® 5 Supermicro Update Manager (SUM) Supermicro Server Manager (SSM) Redfish API
Power Configurations	Power-on mode control for AC power loss recovery ACPI Power Management
Security
Hardware	Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant
Features	Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown
PC Health Monitoring
Voltage	System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support
FAN	Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectorsStatus monitor for speed control
Temperature	Monitoring for CPU and chassis environment Thermal Control for fan connectors
Chassis
Form Factor	2U
Model	CSE-HS829-R1K24P-A
Dimensions and Weight
Height	3.5" (88.9mm)
Width	17.2" (437mm)
Depth	31.6" (803mm)
Package	10.4" (H) x 23.8" (W) x 43.6" (D)
Weight	Net Weight: 39 lbs (17.7 kg) Gross Weight: 69 lbs (31.3 kg)
Available Color	Black front & sliver body
Front Panel
Buttons	Power On/OffUID button
LEDs	HDD activity LAN1 activity Power status System information
Expansion Slots
PCI-Express (PCIe)	4 (Optional) PCIe 5.0 x16 FHFL slot(s) 8 (Optional) PCIe 5.0 x8 FHFL slot(s)
Drive Bays / Storage
Hot-swap	12x 3.5" hot-swap NVMe/SATA/SAS drive bays
M.2	2x NVMe (PCIe Gen4, Boot drive only) M-Key, 22110 (Default)
System Cooling
Fans	4x 8cm heavy duty fans with optimal fan speed control
Air Shroud	1 Air Shroud(s)
Power Supply	1200W Redundant Titanium Level power supplies
Operating Environment
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
Note	Operating Temperature based on configurations

Flexible and Efficient Single-Socket Server Family

The time has arrived when a single-socket server can power workloads with more cores than most 2-socket servers could manage only a short time ago. The 128 cores delivered by 4th Gen AMD EPYC™ processors can power many data center workloads with less CPU cost and lower power consumption. With this processor generation, the reason for moving to two sockets—more I/O and more memory—has been eliminated. Even a single-socket server can have up to 6 TB of memory and 128 lanes of PCIe 5.0 connectivity.

You can strike a new balance in your data center: max out the 6 TB of memory to support the demands of memory-intensive workloads, or choose 3 TB of memory for IT operations.

One 4th Gen AMD EPYC™ processor
Up to 24 DIMMs for up to 6 TB of DDR5 memory
PCIe 5.0 with CXL 1.1+ support
Flexible NVMe, SAS, and SATA3 drive options
Configurable PCIe 5.0 expansion capabilities with CXL 1.1+ memory expansion
Open Compute Project (OCP) 3.0 AIOM slot
Titanium-Level efficient power supplies

Leading Multi-node Architecture with Front or Rear I/O

Enterprise-focused platform designed for single-socket performance and flexibility

Deliver flexibility, power efficiency, memory density, and serviceability to many IT workloads

Supermicro H13 Hyper-U series are the ultimate single processor servers that can offer more cores than most 2 socket servers can, ideal for cloud native workloads, such as virtualization and HCI.
