SYS-222H-TN
2U Hyper with 8 hot-swap 2.5" NVMe/SAS/SATA bays and 4 PCIe 5.0 x16 slots + up to 2 PCIe 5.0 x16 AIOM slots
- Dual Intel® Xeon® 6 6700 series processors with E-cores
- 32 DIMM slots supporting up to 2TB of memory
- Optional PCIe slot configurations up to 8 PCIe 5.0 x8 or 4 PCIe 5.0 x16 slots with support for double-width GPU/Accelerator cards
- Flexible networking options with up to 2 AIOM networking slots (OCP NIC 3.0 compatible)
- 8x 2.5" hot-swap NVMe/SATA/SAS drive bays with optional configurations for 16x/24x 2.5" hot-swap NVMe/SAS/SATA drive bays; 2x internal M.2 NVMe drive slots; Optional RAID support via storage add-on card
Key Applications
- Virtualization
- Software-defined Storage
- High Performance Computing
- Cloud Computing
- Enterprise Server
| Product SKUs | SuperServer SYS-222H-TN |
| Motherboard | Super X14DBM-SP |
| Processor | |
| CPU | Dual Socket E2 (LGA-4710) Intel® Xeon® 6 6700 series processors with E-cores |
| Core Count | Up to 144C/144T; Up to 108MB Cache per CPU |
| Note | Supports up to 330W TDP CPUs (Air Cooled) Supports up to 330W TDP CPUs (Liquid Cooled) |
| GPU | |
| Max GPU Count | Up to 4 double-width or 4 single-width GPU(s) |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| GPU-GPU Interconnect | PCIe |
| System Memory | |
| Memory | Slot Count: 32 DIMM slots Max Memory (1DPC): Up to 2TB 6400MT/s ECC DDR5 RDIMM Max Memory (2DPC): Up to 2TB 5200MT/s ECC DDR5 RDIMM |
| On-Board Devices | |
| NVMe | NVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required) |
| Chipset | System on Chip |
| Network Connectivity | |
| Input / Output | |
| LAN | 1 RJ45 1 GbE Dedicated BMC LAN port(s) |
| USB | 2 USB 3.0 port(s) (rear) 2 USB 3.0 port(s) (Header) |
| Video | 1 VGA port(s) |
| System BIOS | |
| BIOS Type | AMI 64MB SPI Flash |
| Management | |
| Software | SuperCloud Composer Supermicro Server Manager (SSM) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) SuperServer Automation Assistant (SAA) |
| Power configurations | Power-on mode for AC power recovery ACPI Power Management |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
| CPU | Monitors for CPU Cores, Chipset Voltages, Memory |
| FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis | |
| Form Factor | 2U Rackmount |
| Model | CSE-HS219-R000NP |
| Dimensions and Weight | |
| Height | 3.5" (88 mm) |
| Width | 17.3" (438.4 mm) |
| Depth | 29.73" (755.2 mm) |
| Package | 10.12" (H) x 23.82" (W) x 37.28" (D) |
| Weight | Gross Weight: 66 lbs (30 kg) Net Weight: 40 lbs (18.2 kg) |
| Available Color | Silver |
| Front Panel | |
| LED | HDD activity LAN1 activity LAN2 acticity Power Fail Power status System information (overheat/UID) |
| Buttons | Power On/Off UID button |
| Expansion Slots | |
| PCI-Express (PCIe) Configuration | Option A* 4 PCIe 5.0 x16 FH/10.5"L double-width slot(s) 1 PCIe 5.0 x16 AIOM slot(s) (OCP 3.0 compatible) 1 PCIe 5.0 x8 AIOM slot(s) (OCP 3.0 compatible) Option B* 8 PCIe 5.0 x8 (in x16) FH/10.5"L slot(s) 1 PCIe 5.0 x16 AIOM slot(s) (OCP 3.0 compatible) 1 PCIe 5.0 x8 AIOM slot(s) (OCP 3.0 compatible) (*Requires additional parts, please see the optional parts list for details. For more details on PCIe slot configuration options, please refer to the system callout images above.) |
| CXL Support | Up to 4 CXL 2.0 x16/x8 devices |
| Drive Bays / Storage | |
| Drive Bays Configuration | Default: Total 8 bay(s) 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s) Option A: Total 16 bay(s) 16 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s) Option B: Total 24 bay(s) 24 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bay(s) (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) |
| M.2 | 2 M.2 PCIe 5.0 x2 NVMe slot(s) (M-key 2280/22110) |
| System Cooling | |
| Fans | 4 counter-rotating 80x80x38mm Fan(s) |
| Liquid Cooling | Direct to Chip (D2C) Cold Plate (optional) |
| Power Supply | 2x 1200W Redundant (1 + 1) Titanium Level (96%) power supplies 2x 2000W Redundant (1 + 1) Titanium Level (96%) power supplies 2x 1600W Redundant (1 + 1) Titanium Level (96%) power supplies 2x 2600W Redundant (1 + 1) Titanium Level (96%) power supplies |
| Operating Environment | |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
Supermicro X14 Hyper Server
Flagship Performance 1U and 2U Rackmount Systems
- Single and dual socket Intel® Xeon® 6700 series processors with E-cores or 6900 series processors with P-cores
- Free-air and liquid cooling options for maximum performance and efficiency
- Up to 32 DIMM slots supporting DDR5-6400 or 24 DIMM slots supporting DDR5-6400 and MRDIMM 8800MT/s
- NVMe SSD support with up to 24 drives in 2U
- Up to 3 PCIe 5.0 slots in 1U or 8 PCIe 5.0 slots in 2U
- PCIe 5.0 AIOM slots supporting up to 400G networking
X14 Hyper: Best-in-class Performance and Flexibility Rackmount Server
The new X14 Hyper series brings next-generation performance to Supermicro’s range of rackmount servers, built to take on the most demanding workloads in the most proven 1U and 2U form factors. Our modular designed allows customization on storage, expansion slot, network and power supplies to meet the applications requirements. Gracefully balances compute, storage and expansion in a tool-less rackmount design for optimization as well as flexibility and serviceability. The X14 Hyper lineup includes the best-selling dual-socket configurations designed for maximum power and compute density, as well as new single-socket architectures to provide balanced performance with only one processor.
1U DP Hyper
SYS-122H-TN
Up to 12 2.5” NVMe/SAS/SATA
2U DP Hyper
SYS-222H-TN
8 to 24 2.5” NVMe/SAS/SATA
1U UP Hyper
SYS-112H-TN
Up to 12 2.5” NVMe/SAS/SATA
2U UP Hyper
SYS-212H-TN
8 to 24 2.5” NVMe/SAS/SATA
Rackmount Optimized Servers
Supermicro's X14 Rackmount servers offer customers several choices, including single or dual processor configurations, a significant amount of memory capacity, and PCIe expansion slots. In addition, the new DC-MHS (Data Center Modular Hardware System) servers are designed to be installed when designing and implementing a multi-vendor rack scale facility.
| X14 Hyper | X14 CloudDC | X14 WIO | |
|---|---|---|---|
| Positioning | Flagship Enterprise | CSP/Scale-out | Entry-level, Efficiency |
| Segments | HPC, Enterprise, Cloud Service Providers, Storage, Virtualization, Networking | Cloud Service Providers, Hyperscale Data Centers, Enterprise | Virtualization, Cloud Computing, Data Center |
| Sockets | 2/1 | 2/1 | 1 |
| DIMM | 32/16 | 32/16 | 8 |
| PCIe | Up to 3 slots (1 U) Up to 8 slots (2U) | Up to 3 slots (1 U) Up to 6 slots (2U) | Up to 3 slots (1 U) Up to 5 slots (2U) |
| Drives | Up to 24 hot-swap 2.5" | Up to 24 hot-swap 2.5" | 10 hot-swap 2.5"/8 hot-swap 3.5" |
| Key Features | Maximum 1/0 flexibility | DC-MHS | UP platform |
Supermicro X14 Server Solutions
Accelerate Innovation: X14 Server Solutions supporting Intel® Xeon® 6 Processors
