ASG-2115S-NE332R
2U front-loading all-flash storage server with 32 E3.S NVMe drives and PCIe 5.0
- Single Socket SP5 AMD EPYC™ 9004 Series processors. Up to 350W TDP.
- Supports 24 DIMMs with 2DPC, up to 6TB memory capacity with 24 DIMMs of 256GB 3DS RDIMM/RDIMM DDR5 ECC memory
- Two PCIe 5.0 x16 slots & two AIOM connectors (OCP 3.0 SFF compliant)
- 32x hot-swap E3.S (7.5mm) NVMe drive bays
- Redundant Titanium 2000W Power Supplies
Datasheet
Product Specification
| Product SKUs | A+ Server ASG-2115S-NE332R (Silver) |
| Motherboard | Super H13SSF |
| Processor | |
| CPU | Single Socket SP5 AMD EPYC™ 9004 Series Processor (the latest AMD EPYC™ 9004 Series Processor with AMD 3D V-Cache™ Technology) |
| Note | Supports 200W - 350W TDP CPUs (Air Cooled) |
| System Memory | |
| Memory | Memory Capacity: 24 DIMM slots Up to 4TB: 16x 256 GB DRAM Up to 6TB: 24x 256 GB DRAM Memory Type: 4800MHz ECC DDR5 RDIMM;LRDIMM |
| Memory Voltage | 1.1 V |
| Error Detection | ECC |
| On-Board Devices | |
| Chipset | System on Chip |
| Network Connectivity | Via AIOM |
| IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| Input / Output | |
| LAN | 1 RJ45 Dedicated IPMI LAN port |
| USB | 4 USB 3.0 port(s) (2 front; 2 rear) |
| Video | 1 VGA port(s) |
| System BIOS | |
| BIOS Type | AMI 32MB SPI Flash EEPROM |
| Management | |
| Software | IPMI 2.0 KVM with dedicated LAN Super Diagnostics Offline SuperDoctor® 5 Supermicro Update Manager (SUM) Supermicro Server Manager (SSM) Redfish API |
| Security | |
| Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| PC Health Monitoring | |
| CPU | 4+1 Phase-switching voltage regulator Monitors for CPU Cores, Chipset Voltages, Memory |
| FAN | Fans with tachometer monitoring Pulse Width Modulated (PWM) fan connectors Status monitor for speed control |
| Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis | |
| Form Factor | 2U Rackmount |
| Model | CSE-236E3-R2K08P |
| Dimensions and Weight | |
| Height | 3.5" (89.8mm) |
| Width | 17.2" (438.4mm) |
| Depth | 30.8" (789.9mm) |
| Package | 10" (H) x 26.5" (W) x 43.25" (D) |
| Weight | Net Weight: 55 lbs (24.95 kg) Gross Weight: 77 lbs (34.93 kg) |
| Available Color | Silver |
| Expansion Slots | |
| PCI-Express (PCIe) | 2 PCIe 5.0 x16 FH slot(s) 2 PCIe 5.0 x16 AIOM slot(s) |
| Drive Bays / Storage | |
| Hot-swap | 32x E3.S Hot-swap NVMe (1T/2T) drive slots |
| M.2 | 2x PCIe 3.0 (NVMe slots) M-Key, 2280 and 22110 |
| System Cooling | |
| Fans | 4 Heavy Duty 8cm Fan(s) |
| Power Supply | 2000W Redundant Titanium Level power supplies |
| Dimension (W x H x L) | 73.5 x 40 x 203 mm |
| AC Input | 1000W: 100-127Vac / 50-60Hz 1800W: 200-220Vac / 50-60Hz 1980W: 220-230Vac / 50-60Hz 2000W: 220-240Vac / 50-60Hz (for UL only) 2000W: 230-240Vac / 50-60Hz 2000W: 230-240Vdc / 50-60Hz (for China only) |
| +12V | Max: 83A / Min: 0A (100Vac-127Vac) Max: 150A / Min: 0A (200Vac-220Vac) Max: 165A / Min: 0A (220Vac-230Vac) Max: 166A / Min: 0A (230Vac-240Vac) |
| 12V SB | Max: 3.5A |
| Output Type | Backplanes (gold finger) |
| Operating Environment | |
| RoHS | RoHS Compliant |
| Environmental Spec. | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing) |
AI Optimized Storage
Highly Efficient Sustainable Flash
For read-intensive content delivery
Benefits & Advantages
- Maximum density design to support up to 1PB in 2U with next-generation drives
- Direct-attached EDSFF E3.S media for the best thermal and I/O performance
- CPUs with built-in Intel Accelerator Engines to offload storage functions and improve performance
- Flexible topology allows distribution of PCIe lanes based on performance and density requirements
Key Features
- Single AMD EPYC 9004 Series processors
- Supports PCIe 5.0, DDR5 and Compute Express Link (CXL) 1.1
- Up to 24 drives in 1U or 32 drives in 2U
- 2 PCIe 5.0 x16 slots + 2 PCIe 5.0 x16 AIOM slots
All-Flash EDSFF Petascale for Software-Defined Data Center Workloads
Extreme Density, High-Performance All-Flash Servers
Supermicro H13 All-Flash NVMe storage systems powered by AMD EPYC 9004 series processors are designed with the latest EDSFF and CXL technologies allowing unprecedented capacity and performance to enable today's data hungry workloads supporting latest software-defined storage and NVMe over fabrics solutions, as well as in-memory databases.
The new all-flash petascale servers take advantage of 128 PCIe 5.0 lanes, supporting up to 32 E3.S (x2) in 2U, and 16 E3.S drives (x4) in 1U, or configured with 8 E3.S (x4) drives and 4 CXL devices in E3.S 2T (x8) form factor allowing memory expansion.
