WM-D140
14" Windows Rugged Tablet PC with Intel® Core™ i5-1235U
- Intel® Core™ i5-1235U Alder Lake processor
- 14-inch tablet, 1920 x 1080 wide viewing angle LED Panel
- Projected Capacitive Touch screen with Stylus
- Magnesium Alloy Housing with All-Around Elastomeric Rubber
- Thermal Design with Fan cooling system
- Built in stylus holder for left/right hand usage
Datasheet
Product Specification
| Display | |
| Size | 14.0 inches |
| Resolution | 1920x1080 |
| Type | Projected Capacitive Multi Touch |
| Panel Brightness | 500.0 nits |
| Contrast Ratio | 1000:1 |
| View Angles | 89,89,89,89 |
| Bonding | Optical Bonding for Sunlight Viewability |
| System Specification | |
| Processor | 12th Intel® Core™ i5-1235U, 3.3GHz, max 4.4GHz |
| Memory | 1 x 8GB SODIMM DDR5-4800 (up to 32GB) |
| Storage | 256GB M.2 NVMe SSD 512GB M.2 NVMe SSD (Optional) 1TB M.2 NVMe SSD (Optional) 2TB M.2 NVMe SSD (Optional) |
| Security | Trusted Platform Module (TPM) 2.0 Kensington Lock |
| Operating System | Windows 11 IoT Enterprise LTSC (64 bit) |
| WLAN | Support |
| BT | Support |
| WWAN | 4G LTE (Optional) |
| Mechanical | |
| Dimension | 350.35 x 245.66 x 31.6 mm |
| Weight | 2.4 Kg (Without Kickstand), 2.5 Kg (With Kickstand) |
| Cooling System | Fan Design |
| IO Ports | |
| USB Port | 4 x USB 3.2 Type A, 2 x USB 3.0 Type C (PD/ALT Mode) |
| LAN | 1 x RJ45 10/100/1000 Mbps LAN |
| Audio | 2 x 1 watt speaker |
| Indicator | 4x LED Indicator for Power, Battery, WiFi, LTE |
| Environment | |
| Operating Humidity | 30% to 80% RH, noncondensing |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Storage Temperature | -20°C to 60°C (4°F to 140°F) |
| Shock | MIL-STD-810G Method 516.6 Procedure I |
| Vibration | MIL-STD-810G Method 514.6 Procedure I |
| Drop | MIL-STD-810G Method 516.6, 4 ft |
| IP rating | IP65 |
| EMC | 8KV/12KV (contact, Air) |
| Certification | |
| Certification | CE, FCC |
| Security Function | |
| SOTI MobiControl | SOTI MobiControl Compliance |
| Kensington Lock | Kensington Lock Support |
| Control | |
| Button | 1 x Power, 1 x F1, 1 x F2, 1 x Key Lock, 1 x Keyboard, 1 x Home key |
| Power | |
| Battery | 10.9V, typ. 6700 mAh, 73.03Wh LiOn Battery (3S2P) |
| Power Rating | 19V DC |
| Adapter | 100-240V, 50-60Hz / 19V DC / Type-C |
| Accessory | |
| Accessory | Adapter and Power Cord , Standard Battery , Stand with Integrated Handle , Top Handle |
| Camera | |
| Rear Camera | 8MP Rear Camera with autofocus and LED light (Optional) |
D140 Rugged Tablet Series Key Features
The D140 Rugged Tablet is designed to meet the diverse demands of professionals across various sectors, including automotive, logistics, utilities, field services, and beyond. Its long-lasting battery and six customizable function keys enhance productivity during field operations, while the built-in 8MP rear camera ensures seamless documentation and inspections.
With its versatile connectivity options and robust durability, the D140 excels in applications ranging from vehicle diagnostics and equipment inspections to GIS mapping, real-time data analysis, and other industry-specific needs.
- 14-Inch Full HD Display:
Equipped with a 1920 x 1080 resolution screen, the D140 delivers sharp, vibrant visuals, ideal for GIS, mapping, CAD applications and other applications. - Advanced Computing Processor:
Powered by a 12th Gen Intel Core processor, it ensures reliable multitasking, energy efficiency, and smooth operation of data-intensive tasks. - Projected Capacitive Touch:
The glove-compatible touchscreen supports multi-touch inputs, making it easy to use in rugged industrial settings. - Rugged Design with IP65 Protection:
Featuring a cooling fan and an IP65-rated build, the D140 withstands extreme temperatures, water, and dust, ensuring performance in any environment. - Versatile Connectivity:
With built-in Wi-Fi, Bluetooth, 4G, and multiple USB ports, the D140 ensures seamless data exchange and compatibility with industrial peripherals.
