AD-ARK-3534B
Intel® Core™ 12th/13th/14th Gen i3/i5/i7/i9 LGA1700 Expansion Fanless Box PC
- Support Intel® Core™ 12th/13th/14th Gen. i3/i5/i7/i9 processor
- Triple independent display: HDMI + HDMI + Optional Display
- DDR5 SO-DIMM memory support up to 64 GB
- 9-36VDC wide range power input
- Up to 3sets 2.5" hard drive bays, support Intel® SW RAID
- Support up to 4GbE, 8USB, 8COM, 16bit DIO, 2CANBus, TPM2.0
- SUSI API, WISE-DeviceOn, McAfee and Acronis bundled
Datasheet
Product Specification
| Model | ARK-3534B-00A1 |
| Processor | |
| CPU | Intel® 12th generation Core™ I processor/ Pentium®/Celeron® |
| Chipset | H610E |
| Memory | |
| Technology | DDR5 4800 MHz |
| Max. Capacity | 64 GB |
| Socket | 2 x 262 pin DDR5 SO-DIMM |
| Graphics | |
| Graphic Engine | DirectX 12, OpenGL 4.5 HW Encode: H.265/HEVC, H.264/MPEG-4 AVC, MPEG-2, JPEG/MJPEG and VP8. HW Decode: H.265/HEVC, H.264/MPEG-4 AVC, MPEG-2, VC-1/WMV9, JPEG/MJPEG, VP8 and VP9 |
| HDMI | 2 |
| Audio | |
| Main System | Realtek ALC888S, High Definition Audio, Line-out, Mic-in |
| Ethernet | |
| Controller | 2 |
| LAN1 | 10/100/1000 Mbps Intel I219-LM GbE, support Wake On Lan |
| LAN2 | 10/100/1000/2500 Mbps Intel i225 GbE, support Wake On LAN |
| I/O Interface | |
| Serial Port | 4 x RS-232/422/485 port with auto flow control, 2 x RS-232 (additional COM7/8 2 x RS-232 by optional cable) |
| USB Interface | 4 x USB 3.2 (2 x Gen2, 2 x Gen1), 4 x USB 2.0 |
| Expansion | |
| M.2 | 1 x B key (Type: 2280, 3042) + 1 x E Key (Type: 2230) |
| PCI Express x 16 | 1 |
| PCI Express x 4 | 1 |
| Storage | |
| 2.5" HDD/SSD | 2 x 2.5" SATAIII Drive bay (compatible with 15mm height) |
| Other | |
| Watchdog Timer | 255 levels timer interval, setup by software |
| Software Support | |
| Microsoft Windows | Windows 10 |
| Certification | |
| EMC | CE/FCC Class B, CCC, BSMI, UKCA |
| Safety Certifications | CB, UL, CCC, BSMI, UKCA |
| Power Requirement | |
| Power Type | AT/ATX |
| Power Input Votage | 9 ~ 36 VDC |
Use Case: Optimizing Production Efficiency with Agricultural Robots
AI-based agricultural robots increase selectivity precision and robustness within modern agriculture. These unmanned, automated machines are capable of analyzing crops for maturity, harvest logistics, and adaptation to various operating environments.
ARK-3534 was chosen for its powerful CPU and GPU computing power that enables quick and accurate image processing and analysis. The system features 4 x PCIe/ PCI slots, diverse I/O, and flexible expansion options for multiple device connections.
Benefits
- Built-in power supply and optimized thermal solution for CPU
- GPU system integration
- Real-time control with built-in TSN and TCC
- Industrial-grade ruggedized design
High-Performance Edge Computing
AD-ARK-3534 Series
A High-Performance, Multi-Functional Edge Computer for Semiconductor Equipment Applications
- Breakthrough performance with 25+ I/O Connections
- Expandable and reliable design for multi-tasking applications
- Supports up to 4 x PCI/PCIe slots for AI vision, motion, data acquisition, and I/O cards
