AS-iEP-7030E
Industrial IoT Controller supports Intel® 14th Gen Core™ Ultra Processor (Meteor Lake-U/H)
- Intel® 14th Gen Core™ Ultra Processor (Meteor Lake-U/H)
- Scalable power and performance in BGA for edge controller
- Hight Performance New Intel® Xe LPG Graphics Architectures
- New integrated NPU for Dedicated AI Acceleration
- Fan-less and Rugged Design
- Operating Temperature: -20°C to 50/70°C
- Wide Range Power Inputs: 9/19-36 VDC
- 3 x Intel i226-IT LAN, one support vPro
- 2 x Intel i210-AT LAN, support IEEE 802.3AF PoE, for PoE SKU only
- Support Intel® IN-Band ECC
Datasheet
Product Specification
| Processor System | |
| CPU | iEP-7030E Series : Intel® Core™ Ultra processors 155U, 2P+8E, 15W iEP-7031E Series : Intel® Core™ Ultra processors 125U, 2P+8E, 15W iEP-7032E Series : Intel® Core™ Ultra processors 155H, 6P+8E, 28W iEP-7033E Series : Intel® Core™ Ultra processors 125H, 4P+8E, 28W |
| BIOS | AMI SPI 256 Mbit |
| Chipset | MCP |
| Memory | |
| Technology | Dual Channel DDR5 5600 MHz |
| Capacity | Up to 64GB |
| Socket | 2 x 262-pin SO-DIMM |
| Graphics | |
| Controller | Intel® Iris® Xe Graphics |
| DisplayPort | DisplayPort 1.4a DP++ Max resolution up to 4096x2160@60Hz |
| VGA | Max resolution up to 1920x1200@60Hz |
| Expansion Slot | |
| M.2 | 1 x M.2 3042/3052 Key B (PCIe Gen3x1/USB3.2 mode) - Support 4G LTE/5G module 1 x M.2 2230/2260 Key E (CNVi/PCIe Gen3x1/USB2.0 mode) - Support Wifi/BT module |
| RF& Antenna | 7 x SMA connector hole reserved, support for Basic/5G SKU 5 x SMA connector hole reserved, support for PoE/5LAN/8DIO SKU |
| Audio | |
| Interface | Realtek ALC897, High Definition Audio |
| Ethernet | |
| Controller/ Speed | LAN1: Intel® I226IT with 10/100/1000/2500 Mbps, supports Intel vPro® Enterprise LAN2/LAN3: Intel® I226IT with 10/100/1000/2500 Mbps LAN4/LAN5: Intel® I210AT with 10/100/1000 Mbps (For 5LAN SKU) PoE1/PoE2: Intel® I210AT. PoE output max.15.4W/port, each port supports IEEE 802.3AF PoE. (For PoE SKU) |
| Connector | RJ45 |
| Front I/O | |
| Audio | 1 x Mic-in 1 x Line-out |
| COM | 2 x RS-232/422/485 |
| Ethernet | 3 x 2.5G LAN |
| DisplayPort | 1 x DP++ 1.4a |
| USB | 3 x USB 3.2 Gen2x1 1 x USB 2.0 |
| LED | 2 x Diagnostic LED 2 x DC-IN LED |
| DC-IN | 2 x 3-pin Phoenix type |
| Power Button | 1 (with LED) |
| Rear I/O | |
| SIM Card | 1 x Nano SIM Card slot |
| Micro SD Card | 1 x Micro SD card slot (Support SD specification v3.0 UHS-I: SDR25/SDR50) |
| Manageability / Security | |
| Manageability | Intel® In-Band Manageability |
| Security | TPM2.0 |
| Top I/O | |
| COM | 2 x RS-232/422/485 |
| Digital I/O | 8DIs/8DOs with sink/source isolation 36V for 8DIO SKU only (2x10-pin connector) |
| Ethernet | 2 x 1G LAN for 5LAN SKU only |
| PoE | 2 x 1G LAN, support IEEE 802.3AF for PoE SKU only |
| LED | 2 x PoE LED for PoE SKU only |
| Storage | |
| M.2 | 1 x M.2 2280 Key M (PCIe Gen4 x4) |
| Watchdog Timer | |
| Output | From Super I/O to drag RESETCON# |
| Interval | 256 Segments, 0, 1, 2, ...255sec |
| Power Requirements | |
| DC Input | For Basic/5LAN/5G/8DIO SKU : 2 x 3-pin phoenix type for 9 to 36V DC input For PoE SKU : 2 x 3-pin phoenix type for 19 to 36V DC input OVP, UVP, OCP, plus 80V surge protection |
| AC to DC Adaptor (Option) | Adapter 120W for Basic/5LAN/5G SKU - AC input 100-240Vac, 1.8A 50-60Hz, DC output 19V, 6.32A, Adapter 330W for PoE SKU only - AC input 100-240Vac, 4.2A 50-60Hz, DC output 24V, 13.75A |
| Environment | |
| Operating Temp | 15W CPU: - For Basic/5LAN-WIFI SKU : -25°C~70°C (-13°F~158°F) - For 5G/5LAN-5G SKU with 4G LTE module : -25°C~60°C (-13°F~140°F) - For 5G/5LAN-5G SKU with 5G module : -25°C~55°C (-13°F~131°F) - For PoE SKU : -25°C~50°C (-13°F~122°F) 28W CPU: - For all SKU : -25°C~50°C (-13°F~122°F) (with airflow 0.5~0.8m/s) |
| Storage Humidity | -40°C ~ 85°C (-40°F~185°F) |
| Humidity | ~95% @ 40°C (non-condensing) |
| Vibration | Operating: 5 Grms, 5-500 Hz, 3 axes with SSD |
| Shock | Operating 100 G, half sine 11 ms duration with SSD |
| ESD | Contact +/-8 KV, Air +/-15 KV |
| EMC | CE and FCC Class A (EN61000-6-4/-2) |
| Safety | LVD |
| Mechanical | |
| Construction | Aluminum |
| Dimensions (L x W x H) | For Basic/8DIO SKU : 55 x 170 x 134 mm For PoE/5LAN/5G SKU : 68 x 170 x 134 mm |
| Mounting (Option) | For Basic/8DIO SKU : DIN-Rail, Wall Mount, VESA Mount For PoE/5LAN/5G SKU: Wall mount, Din Rail |
| Net Weight | TBD |
| Others | |
| OS Support | Windows 11 / Linux |
| Packing List | 3 x M2*2 Screw Package 2 x 3-pin phoenix connector 1 x System QIG |
Industrial IoT Controller
The Industrial IoT Controller features high computing power with a compact and rugged design for mission-critical applications. The Series provides flexible IOs and ranged expansion slots for various communications, flawlessly connecting edge-to-cloud in various Edge AI applications.
