AS-IMB-1238

Mini-ITX Motherboard supports Intel® 14th/13th/12th Gen Core™ Processors with Q670 chipset

Anewtech-Systems Industrial-Motherboard AS-IMB-1238 Mini-ITX Motherboard Asrock Industrial
  • Intel® 14th/13th/12th Gen (Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) Core™ Processors with Q670 chipset
  • 2 x 262-pin SO-DIMM DDR5 4800/5600 MHz, up to 96GB (48GB per DIMM)
  • 1 x PCIe x16 (Gen5), 4 x USB 3.2 Gen2, 2 x USB 3.2 Gen1, 4 x USB 2.0, 1 x M.2 Key B, 1 x M.2 Key E, 2 x M.2 Key M, 4 x COM, 4 x SATA3
  • 1 x Intel 2.5 Gigabit LAN, 1 x Intel 1 Gigabit LAN
  • Supports Quad display, 1 x HDMI 2.0b, 1 x HDMI 1.4b, 1 x DP 1.4a, 1 x LVDS or eDP
  • TPM 2.0 onboard IC
  • Supports Intel® vPro, VMD RAID 0/1/5/10
  • ATX-PWR (24+4-pin) and +12V DC-In co-design
Datasheet
Product Specification
Anewtech-Systems-Industrial-Motherboard-AS-IMB-1238-asrock-industrial
Processor System
CPUIntel® 14th/13th/12th Gen (Raptor Lake-S Refresh/Raptor Lake-S/Alder Lake-S) Core™ Processors, up to 65W
ChipsetIntel® Q670
SocketLGA1700
BIOSAMI SPI 256 Mbit
Form Factor
DimensionsMini-ITX (6.7-in x 6.7-in x 1.5-in, 17.0 cm x 17.0 cm x 3.8 cm)
Memory
TechnologyDual Channel DDR5 4800/5600 MHz*
*Actual memory frequency depends on the CPU types and DRAM modules
*If motherboard ambient temp. is over 55ºC, the memory heatsink should be added to avoid thermal issue
Capacity96 GB (48 GB per DIMM)
Socket2 x 262-pin SO-DIMM
Graphics
ControllerIntel® UHD Graphics
HDMIHDMI 2.0b
Max resolution up to 4096x2160@60Hz
HDMI 1.4b
Max resolution up to 4096x2160@30Hz
DisplayPortDisplayPort 1.4a, DP++
Max resolution up to 4096x2160@60Hz
LVDSDual channel 24 bit up to 1920x1200@60Hz
eDPMax resolution up to 1920 x 1200@60Hz
MultiDisplayQuad Display
Expansion Slot
PCIe1 x PCIe x16 (Gen5, Support riser card x8/x8)
M.21 x M.2 (Key E, 2230) with PCIe x1, USB 2.0 and CNVi for Wireless
1 x M.2 (Key B, 3042/3052) with PCIe x1, USB 3.2 Gen1, USB 2.0 and SIM for 4G/5G
SIM Socket1 x Socket connected to M.2 Key B
Audio
InterfaceRealtek ALC897, High Definition Audio. Line-out,Mic-in
Ethernet
Controller/ SpeedLAN1: Intel® I226V with 10/100/1000/2500 Mbps
LAN2: Intel® I219LM with 10/100/1000 Mbps, supports vPro
Connector2 x RJ-45
Rear I/O
HDMI1 x HDMI 2.0b
1 x HDMI 1.4b
DisplayPort1 x DP 1.4a++
Ethernet1 x 2.5 Gigabit LAN
1 x 1 Gigabit LAN
USB4 x USB 3.2 (Gen2)
2 x USB 2.0
Audio2 (Mic-in, Line-out)
COMCOM1, COM2 (RS-232/422/485)
Internal Connector
USB2 x USB 3.2 Gen1 (1 x USB 3.2 header)
2 x USB 2.0 (1 x 2.54 pitch header)
COMCOM3, COM4 (RS-232)
GPIO4 x GPI, 4 x GPO
LVDS1
eDP1
SATA PWR Output1
Speaker Header1
Security
TPMTPM 2.0 onboard IC
Storage
M.21 x M.2 (Key M, 2242/2280) with PCIe Gen4 x4 for SSD
1 x M.2 (Key M, 2242) with PCIe Gen4 x4 and SATA3 for SSD*
*Recommend using M2X4-SATA-4P module to support extra 4 SATA ports (Support by special BIOS)
SATA4 x SATA3 (6Gb/s)
RAIDIntel® VMD RAID 0/1/5/10
**supported by identical interface (PCIe or SATA)
PCIe interface: M.2 Key B + M.2 Key M1/2 or 2*M.2 Key M
SATA interface: SATA port
Watchdog Timer
OutputFrom Super I/O to drag RESETCON#
Interval256 Segments, 0, 1, 2, ...255sec
Power Requirements
Input PWRATX PWR (24+4-pin) and +12V DC-In co-design
Power OnAT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on after power input ready
Environment
Operating Temp0ºC ~ 70ºC
Storage Temp-40° C ~ 85° C
Operating Humidity5% ~ 90%
Storage Humidity5% ~ 90%

Industrial Motherboards with Intel® Core 14th Gen Processor Optimized for Edge Performance and Flexibility

Anewtech-systems-industrial-motherboard-miniitx-motherboard-micto-atx-motherboard-asrock-industrial-singapore
Intel® Core 14th Gen Processors Motherboard with DDR5
ChipsetH610Q670W680
Mini-ITX (High Rise I/O)IMB-1237IMB-1238IMB-X1238
Mini-ITX (Thin I/O)IMB-1239-WVIMB-1240-WVIMB-X1240-WV
Micro-ATXIMB-1315IMB-1316IMB-X1316 , IMB-X1316-10G
ATXIMB-1713IMB-1714IMB-X1714
Intel Core 14th Gen Processors Motherboard with DDR4
Mini-ITX (High Rise I/O)IMB-1230 , IMB-1241 , IMB-1242IMB-1231IMB-X1231
Mini-ITX (Thin I/O)IMB-1232-WVIMB-1233-WVIMB-X1233-WV
Micro-ATX IMB-1314IMB-X1314
ATX IMB-1712IMB-X1712
