SYS-212HA-TN

2U UP Hyper with 8 hot-swap 2.5” NVMe/SAS/SATA bays and up to 3 PCIe 5.0 + 1 PCIe 5.0 AIOM slots

Anewtech-Systems-Rackmount-Server-Supermicro-SYS-212HA-TN Intel® Xeon® 6900
  • Hyper is a flagship performance rackmount server designed for scale-out cloud workloads.
  • Single Intel® Xeon® 6 6900 series Processor.
  • 12 DIMM slots supporting up to 3TB of 8800 MRDIMM
  • Double width add-on card support.
  • Flexible networking options with 1 AIOM networking slot (OCP NIC 3.0 compatible).
  • Breeze through high throughput workloads with PCIe 5.0 NVMe drive support.
  • Trusted Platform Module (TPM) 2.0 onboard.
  • Modularized and Tool-less design for easy serviceability

Key Applications

  • Virtualization
  • Software-defined Storage
  • AI Inference and Machine Learning
  • Cloud Computing
  • Enterprise Server
  • Data Center Optimized
  • Database Processing and High Density Storage
Datasheet
Product Specification
Anewtech-Systems-Rackmount-Server-Supermicro-SYS-212HA-TN-Supermicro-Singapore
Anewtech-Systems-Rackmount-Server-Supermicro-SYS-212HA-TN-Supermicro-Superserver
Product SKUsSuperServer SYS-212HA-TN
MotherboardSuper X14SBH-AP
Processor
CPUSingle Socket BR (LGA-7529)
Intel® Xeon® 6900 series processors with P-cores
Core CountUp to 128C/256T; Up to 504MB Cache
NoteSupports up to 500W TDP CPUs (Air Cooled)
System Memory
MemorySlot Count: 12 DIMM slots
Max Memory (1DPC): Up to 3TB 8800MT/s ECC DDR5 MRDIMM
Max Memory (1DPC): Up to 3TB 6400MT/s ECC DDR5 RDIMM
On-Board Devices
NVMeNVMe; RAID 0/1/5/10 support(Intel® VROC RAID key required)
ChipsetSystem on Chip
Network ConnectivityVia AIOM
Input / Output
LAN1 RJ45 1 GbE Dedicated BMC LAN port
USB2 USB 3.0 ports(rear)
Video1 VGA port
System BIOS
BIOS TypeAMI 64MB SPI Flash
Management
SoftwareSuperCloud Composer
Supermicro Server Manager (SSM)
Super Diagnostics Offline (SDO)
Supermicro Thin-Agent Service (TAS)
SuperServer Automation Assistant (SAA) New!
Power configurationsPower-on mode for AC power recovery
ACPI Power Management
Security
HardwareTrusted Platform Module (TPM) 2.0
Silicon Root of Trust (RoT) – NIST 800-193 Compliant
FeaturesCryptographically Signed Firmware
Secure Boot
Secure Firmware Updates
Automatic Firmware Recovery
Supply Chain Security: Remote Attestation
Runtime BMC Protections
System Lockdown
PC Health Monitoring
CPUMonitors for CPU Cores, Chipset Voltages, Memory
FANFans with tachometer monitoring
Status monitor for speed control
Pulse Width Modulated (PWM) fan connectors
TemperatureMonitoring for CPU and chassis environment
Thermal Control for fan connectors
Chassis
Form Factor2U Rackmount
ModelCSE-HS201-R000NFP
Dimensions and Weight
Height3.5" (88.9 mm)
Width17.2" (437 mm)
Depth31.74" (806.2 mm)
Package9.96" (H) x 26.46" (W) x 43.31" (D)
WeightGross Weight: 75 lbs (34 kg)
Net Weight: 45 lbs (20.5 kg)
Available ColorSilver
Front Panel
LEDHDD activity
LAN1 activity
Power status
System information
ButtonsPower On/Off
UID button
Expansion Slots
PCI-Express (PCIe) ConfigurationOption A
1 PCIe 5.0 x16 FHFL double-width slot
1 PCIe 5.0 x16 FH/10.5"L double-width slot
1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible)
Option B
1 PCIe 5.0 x16 FHFL double-width slot
2 PCIe 5.0 x8 FH/10.5"L slots
1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible)
Drive Bays / Storage
Drive Bays ConfigurationDefault: Total 8 bays
8 front hot-swap 2.5"
NVMe*/SAS*/SATA* drive bays
(*NVMe/SAS/SATA support may require additional storage controller and/or cables)
M.22 M.2 NVMe slots (M-key 2280/22110/25110; VROC required for RAID)
System Cooling
Air Shroud1 CPU Air Shroud
Fans6 counter-rotating 60x60x56mm Fan(s)
Power Supply
2x 1200W2x 1200W Redundant (1 + 1) Titanium Level (96%) power supplies
2x 1300W2x 1300W Redundant (1 + 1) Gold (Certification Pending) Level power supplies
2x 1600W2x 1600W Redundant (1 + 1) Titanium Level (96%) power supplies
2x 2600W2x 2600W Redundant (1 + 1) Titanium Level (96%) power supplies
Operating Environment
Environmental Spec.Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
Best-in-class Performance and Flexibility Rackmount Server

Supermicro X14 Hyper Server



Flagship Performance 1U and 2U Rackmount Systems

  • Single and dual socket Intel® Xeon® 6700 series processors with E-cores or 6900 series processors with P-cores
  • Free-air and liquid cooling options for maximum performance and efficiency
  • Up to 32 DIMM slots supporting DDR5-6400 or 24 DIMM slots supporting DDR5-6400 and MRDIMM 8800MT/s
  • NVMe SSD support with up to 24 drives in 2U
  • Up to 3 PCIe 5.0 slots in 1U or 8 PCIe 5.0 slots in 2U
  • PCIe 5.0 AIOM slots supporting up to 400G networking
