WM-S101M9L
10.1" ARM A73 + A53 Rugged Tablet PC
- 10.1” 1280 x 800 TFT LCD Display
- 8.0 MP Camera in Front Side
- 13.0 MP Rear Camera (with LED auxiliary light, Auto Focus)
- 4 GB RAM + 32 GB eMMC
- Android™ 11.0
- Integrated 1D/2D Barcode Reader (Optional)
- Integrated NFC Module (Optional)
Datasheet
Product Specification
Custom Configuration
| Display | |
| Size | 10.1 inches |
| Type | Projected Capacitive Multi Touch |
| Resolution | 1280x800 |
| Panel Brightness | 400 nits |
| Contrast Ratio | 1000:1 |
| View Angles | 80,80,80,80 |
| Bonding | Optical Bonding for Sunlight Viewability |
| Viewability | Anti-Glare touch treatment |
| Touch Mode | Support Hand / Gloves and Rain Mode |
| System Specification | |
| Processor | ARM A73 x 4 (2.0 GHz) + A53 x 4 (2.0 GHz) |
| Memory | 4GB |
| Storage | 32GB |
| Operating System | Android 11.0 |
| WLAN | Support |
| BT | Support |
| WWAN | 4G/LTE (Optional) |
| GNSS | GPS/GLONASS |
| RFID | NFC (Read / Write, Peer to Peer mode) (Optional) |
| Sensors | Ambient Light Sensor, E-Compass, Gyro, Acceleration Sensors |
| Camera | |
| Front Camera | 8MP Camera |
| Rear Camera | 13MP Camera with LED Auxiliary Light (Auto Focus) |
| Mechanical | |
| Dimension | 268 x 187 x 22.2 mm |
| Weight | 1.0 kg |
| IO Ports | |
| USB Port | 1 x USB Type C OTG 1 x USB Type A |
| LAN | 1 x RJ45 |
| Video | 1 x Micro HDMI |
| Audio | 1 x Audio Combo connector (Mic in or Line Out) 1 x Speaker |
| SD Card Slot | 1 x Micro SD Card Slot |
| SIM Card Slot | 1 x SIM Card Slot |
| Indicator | 2 x LED Indicators (Power, Battery) |
| Docking Connector | 1 x Docking Connector |
| Environment | |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Operating Temperature | -10°C to 50°C (Battery mode) |
| Storage Temperature | -30°C to 70°C |
| Shock | MIL-STD-810H Method 516.6 Procedure I |
| Vibration | MIL-STD-810H Method 514.6 Procedure I |
| Drop | MIL-STD-810H Method 516.6, 4 ft |
| IP rating | IP65 Certified, Waterproof and Dustproof |
| Certification | |
| Certification | CE, FCC |
| Control | |
| Button | 1 x Power Button, 2 x Function button |
| Power | |
| Battery | 11.4V, typ. 3500 mAh Li-Ion Battery(39.9W), Support Warm Swap function (Optional) |
| Battery Operating Time | 10Hr |
| Power Rating | 19V |
| Adapter | 19V 3.42A Adapter |
| Security Function | |
| SOTI MobiControl | SOTI MobiControl Compliance |
| Kensington Lock | Kensington Lock |
| Barcode Scanner | |
| Barcode Scanner | 1D/2D Barcode Reader (Optional) |
| Accessory | |
| Accessory | Adapter and Power Cord Standard Battery |
| Optional Accessory | Hand Strap, Shoulder Strap, Battery Charger, Capacitive Stylus, Vehicle Charger, Vehicle Docking, Carry Bag, Desk Dock, Micro SD Card, HDMI Adapter |
